Skid steer attachments:

• GRAPPLER
• BUCKETS
• BREAKER
• BUCKET WITH GRAPPLER ATTATCHMENTS

Engine

Engine Cooling Liquid
Emissions Tier (EPA) N/A
Engine Fuel Diesel
Horsepower 22.5 HP
Turbocharged Engine N/A

Performance

Rated Operating Capacity (SAE) 700 lbs
Tipping Load 1455 lbs
Operating Weight 2708 lbs
Travel Speed 6.5 mph
Travel Speed (2-speed option) N/A

Capacities

Fuel Tank 6.5 gal

Hydraulic System

System Relief @ Quick Couplers 3000 psi
Auxiliary Std Flow N/A
Auxiliary High Flow N/A

Dimensions

Length 100.5 in
Length without Attachment 75.5 in
Length with Standard Bucket 100.5 in
Width 35.4 in
Width (with bucket) 36 in
Height 71.4 in
Height with Operator Cab 71.4 in
Height to Bucket Hinge Pin 94.5 in
Reach @ Maximum Height 18.5 in
Turning Radius 61.3 in
Wheelbase 28.4 in
